Description of Ion Chromatography Instrument:
Ion chromatography instrument is a kind of high performance liquid chromatography, as a kind of liquid chromatography method for determining the types and contents of anions, cations and some polar organic substances, it has been widely used in many fields, such as environmental monitoring, food analysis, natural water industry, agriculture, geology and so on. Overall, the Ion Chromatography Instrument is a versatile and reliable analytical tool that is essential for a wide range of research and testing applications. Its advanced features and capabilities make it an ideal choice for any laboratory or research facility.
Technical Parameters of Ion Chromatography Instrument:
| 10μL-4000μL Injection Volume Ion Chromatography Instrument for Food Safety Detecttion |
| Product Name | Ion Chromatography Instrument |
| Working Conditions | |
| Working Power | 220V, 50Hz |
| System Parameters | |
| Qualitative Repeatability | ≤1% |
| Quantitative Repeatability | ≤1% |
| Pump System | |
| Flow Rate | 0.001～15.000mL/min |
| Pressure Range | 0~42MPa |
| Flow Rate Setting Error | ＜0.2% |
| Flow Rate Stability | ＜0.2% |
| Eluent | |
| Flow Rate Range | 0.001~3.000ml/min |
| Eluent Concentration Range | KOH/MSA 0.1~100.0mM |
| Accuracy of Concentration | 0.1mM |
| Max Working Pressure | 21Mpa (3000psi) |
| Autosampler (AS2800 series) | |
| Quantitative Repeatability | Full loop injection ＜0.5%RSD |
| Linearity | ＞0.9995 |
| Injection Positions | 48 Positions |
| Working Temperature | 10~40°C |
| Sample Bottle | 5mL/100mL |
| Injection Volume | 10μL~400μL |
| Autosampler (AS3110 Series) | |
| Injection Positions | 120/64/92 positions for optional |
| Cooling Temperature | 4~30°C |
| Injector | Standard 500μL, options 250μL, 100μL, 2500μL |
| Column Oven | |
| Temperature Range | Room temperature, ＋5℃~70℃ |
| Temperature Control Stability | ≤0.1°C |
| Temperature Setting Error | 0.05°C |
| Column Capacity | 250mm and 150mm |
| Suppressor | |
| Dead Volume | 50μL |
| Suppression Capacity | 170ueq/min |
| Pressure Resistance | 3Mpa |
| Conductivity Detector | |
| Baseline Noise | ≤0.0005μS/cm |
| Baseline Drift | ≤0.0005μS·cm-1/30min |
| Min Detection Concentration(Cl) | ≤0.0005μg/mL |
| Min Detection Concentration (Li) | ≤0.0002μg/mL |
| Cell Volume | ≤0.4μL |
| Detector Resolution | 0.00238nS/cm |
| Temperature Setting Error | ±0.01°C |
| Ampere Detector | |
| Drive Voltage Range | -2.048V---2.048V |
| Drive Voltage Resolution | 0.001V |
| Single Input Range | Integral mode, 50pc---200uC |
| DC mode | 1pA---74uA |
| Cell Volume | ＜0.2μL |
| Min Detection Concentration | I: 0.001μg/mL |
Applications of Ion Chromatography Instrument:
The Ion Chromatography Instrument is widely used in various fields, including environmental monitoring, food and beverage analysis, pharmaceutical analysis, and chemical research.
In environmental monitoring, it can be used to detect pollutants in water and soil samples.
In the food and beverage industry, it can be used to analyze the composition of various products.
In pharmaceutical analysis, it can be used to determine the purity of drugs and their active ingredients.
In chemical research, it can be used to identify and quantify the ions present in a sample.
The Ion Chromatography Instrument is an essential tool for any laboratory that requires accurate and reliable analysis of ions in samples. Wayeal's IC6300 model is a high-quality instrument that offers precise results and is suitable for a wide range of applications. Its robust design and reliable performance make it a valuable investment for any laboratory.
